- SF3300-P Four-posision unfolding feerder
Functional features:
1. The feeding station of the chain is driven by the reducer, and four feeding stations are set up. Two sets of feeding robots are designed for each feeding station, one set of feeding robots is working, and the other set is in the state of waiting to be fed, which improves the working efficiency;
2, the use of 3 sets of distribution manipulator, improve the work efficiency of the distribution machine;
3. Set the incoming filter brush and the outgoing smooth brush (optional) to improve the flatness of the cloth;
4, set the cloth delivery mode and the distribution mode, can handle the pillowcase square towel and other small specifications of linen switch convenient and fast;
5, the distribution manipulator is driven by the same motor, and the length of the cloth is accurately measured by the photoelectric sensor, so that the cloth is always in the set feeding position;
6, the tensile force of the cloth is protected by the same motor torque and photoelectric sensor, reducing the damage rate of the cloth;
7, the rear conveyor line is set up lifting cylinder, can quickly lift the rear conveyor line, convenient ironing machine maintenance or can be wax cloth, pillowcase directly into the ironing machine;
8, perfect self-diagnosis function and safety protection can quickly locate the fault location and the cause of the fault, easy to daily use and maintenance of the machine;
9, the use of 10-inch touch screen programmable computer control, each station has statistical function, accurate measurement of the amount of feed, easy for operators to manage.
